40 Rockwell Automation Publication LDC-UM001B-EN-P - March 2011
Chapter 5 Wire the LDC-Series Linear Motor
Signal and Wire Definitions
for Flying Lead Components
For linear motors, catalog numbers LDC-xxxxxxx-xxT20, wire them by using the
wiring diagram on page 79
. Wire colors and signal types are shown here; for wire
gauge information see page 71
.
Linear Motor Coil
These are the wire colors and signals for the linear motor-coil power and thermal
protection cables, catalog numbers LDC-xxxxxxx-xxT20.
Table 3 - Power Signals
These are the PTC thermistor sensor wire colors and signals for the linear motor
coil power and thermal protection cables, catalog number LDC-xxxxxxx-xxT20.
Table 4 - PTC Thermistor Sensor Signals
Color Signal Comments
Red Motor Phase U (A) • Observe maximum applied voltage specification.
• Consult the drive manual or supplier for specific
wiring instructions to the drive. Wiring is phase/
commutation sensitive.
White Motor Phase V (B)
Black Motor Phase W (C)
Green Motor Ground • Terminate per drive manual instructions.
• Shield is not connected to the motor frame.
Shield Cable Shield
ATTENTION: Disconnect the input power supply before installing or
servicing the motor. Motor lead connections can short and cause damage
or injury if not well secured and insulated. Insulate the connections, equal
to or better than the insulation on the supply conductors. Properly ground
the motor per the selected drive manual.
Color Description Signal
Black PTC thermistor sensor + TS+
Black PTC thermistor sensor - TS-
