Rockwell Automation Publication LDC-UM001B-EN-P - March 2011 11
Chapter
1
Safety Considerations
Introduction
This chapter describes the safety issues encountered while using a linear motor
and the precautions you can take to minimize risk. Potential hazards discussed
here are identified by labels affixed to the device.
Labels
Here you will find the safety and identification labels affixed to your linear motor
components. To prevent injury and damage to the linear motor, review the safety
label and its details and location before using the linear motor
.
Topic Page
Labels 11
High Energy Magnets 13
Vertical or Incline Installation 14
Operational Guidelines 15
Table 1 - Safety Labels
Title Location Label Details
Magnetic Field
Danger
A The Magnetic Fields label identifies non-ionizing radiation
found in the magnet tracks. Magnet tracks are constructed
with strong magnets. Strong magnets can disrupt the
functionality of automatic implantable cardioverter
defibrillators (AICD); people with a pacemaker should not
work near the magnet tracks. Maintenance personnel
working near the magnet tracks should avoid the use of
metallic tools and secure items, such as a badge clip and
other personal effects, that could be attracted by the strong
magnets. Strong magnets can erase magnetic media. Never
let credit cards or electronic media contact or come near the
magnet tracks.
DANGER
MAGNETIC FIELDS
LOCATED IN THIS AREA.
Can be harmfull to
pacemakers and other
sensitive equipment.
