N10:115 Torque Reg. Integral Gain U.015 Tu n a ble 2000 = 200.0

N10:116 Fld. Weakening Start RPM U.016 Configurable 1785 = 1785 RPM

N10:117 Motor Top Speed U.017 Configurable 7200 = 7200 RPM

N10:118 AC Line Volts U.018 Configurable 460 = 460 V

N10:119 Flux Cur. Reg. Prop. Gain U.019 Tun a bl e 500 = 5.00

N10:120 Flux Cur. Reg. Integral Gain U.020 Tu n able 400 = 40.0

N10:121 Rotor Time Constant U.021 Tun a bl e 100 = 100 msec

N10:122 Motor Nameplate HP U.022 Configurable 10 = 1.0 HP

N10:123 Low DC Bus Flt. Avoid En. U.023 Tu n a ble 0 = off; 1 = on

N10:124 High DC Bus Flt. Avoid En. U.024 Tun ab le 0 = off; 1 = on

N10:125 Zero Speed Hold Time U.025 Tu n abl e 1 = 0.1 sec

N10:126 Current Compounding Gain U.026 Tu n able 1 = 0.001

N10:127 Inertia Compensation Gain U.027 Tu n able 1 = 0.001

N10:128 Losses Compensation Gain U.028 Tun a bl e 1 = 0.001

N10:129 Reserved U.029 Note 1

N10:130 SVC Slip Adjust U.030 Tun a bl e 100 = 1.00

N10:131 SVC Sync Direction U.031 Configurable 0 = Off; 1 = F; 2 = r; 3 = Fr; 4 = rF

N10:132 SVC Flux Cur. Reg. Gain U.032 Tun a bl e 500 = 500 rad/sec

N10:133 Reserved U.033 Note 1

N10:134 Reserved U.034 Note 1

N10:135 Reserved U.035 Note 1

N10:136 Reserved U.036 Note 1

N10:137 Reserved U.037 Note 1

N10:138 Reserved U.038 Note 1

N10:139 Reserved U.039 Note 1

N10:140 OCL Feedback Source U.040 Configurable 0 = TS analog in; 1 = Spd Loop PI out

N10:141 OCL Lead/Lag Select U.041 Tu n abl e 0 = bypass; 1 = lead/lag; 2 = lag/lead

N10:142 OCL Lead/Lag Low Freq. U.042 Tu n a ble 1 = 0.01 rad/sec

N10:143 OCL Lead/Lag Ratio U.043 Tun a bl e 1 = 1

N10:144 OCL Reference Gain U.044 Tun a bl e 1 = 0.001

N10:145 OCL Proportional Gain U.045 Tu n abl e 10 = 0.10

N10:146 OCL Integral Gain U.046 Tun a bl e 1 = 0.01

N10:147 OCL Trim Range Percent U.047 Tu n able 1 = 0.1% (gain of 0.001)

N10:148 OCL Prop.Trim EnableFil U.048 Configurable 0 = off; 1 = on

Table 7.1 – File N10:X (Drive Read/Write Parameters)

File

Address Parameter Name

Parameter

Number Type Notes

Note 1: This parameter cannot be changed from the ControlNet network, or it is reserved. When writing to this parameter, use

a value of 0. When you read this parameter, you receive a value of 0.
