Owner's manual

Register Map 7-3
N10:58 Reserved P.058 Note 1
N10:59 Reserved P.059 Note 1
N10:60 Node Number P.060 Read Only 2 to 99
N10:61 Prog/Run Mode P.061 Configurable 0 = stop,1 = not stop,
3 = term strip control
N10:62 Option Port: Communication
Loss Response
P.062 Tun a bl e 0 = IET flt; 1 = hold last; 2 = term strip
reference; 3 = term strip control
N10:63 Option Port: Network Ref.
Source (not used)
P.063 Note 1
N10:64 Option. Port: Network Trim
Ref. Source (not used)
P.064 Note 1
N10:65 CNI Version P.065 Read Only 5200 = CNI version 2.00
N10:66 Network Output Reg 1 P.066 Tu n able 0 to 12
N10:67 Network Output Reg 2 P.067 Tu n able 0 to 12
N10:68 Network Output Reg 3 P.068 Tu n able 0 to 12
N10:69 Network Output Reg 4 P.069 Tu n able 0 to 12
N10:70
|
N10:89
Reserved P.070
|
P.089
Note 1
N10:90 Diagnostics Source P.090 Tu n able 0 to 19
N10:91 Diagnostics Display P.091 Read Only
N10:92 Reserved P.0920 Note 1
N10:93 Reserved P.093 Note 1
N10:94 Reserved P.094 Note 1
N10:95 Power Module Output Amps P.095 Read Only 100 = 10.0 A
N10:96 Reserved P.096 Note 1
N10:97 Reserved P.097 Note 1
N10:98 Software Version Number P.098 Read Only 600 = version 6.00
N10:99 Power Module Type P.099 Read Only 4.005 = 460 V, 5 HP
H Parameters
N10:100 Motor Nameplate Volts H.000 Configurable 460 = 460 V
N10:101 Motor Nameplate Base Freq H.001 Configurable 600 = 60.0 Hz
N10:102 Motor Nameplate Amps H.002 Configurable 100 = 10.0 A
N10:103 Torque Boost Voltage H.003 Configurable 5 = 0.5%
N10:104 Slip Compensation H.004 Tun a bl e 0 = 0.0%
N10:105 DC Braking Enable H.005 Tu n abl e 0 = off; 1 = on
N10:106 DC Braking Start Frequency H.006 Tu n a ble 50 = 5.0 Hz
Table 7.1 – File N10:X (Drive Read/Write Parameters)
File
Address Parameter Name
Parameter
Number Type Notes
Note 1: This parameter cannot be changed from the ControlNet network, or it is reserved. When writing to this parameter, use
a value of 0. When you read this parameter, you receive a value of 0.
