Register Map 7-1
CHAPTER 7
Register Map
Table 7.1 – File N10:X (Drive Read/Write Parameters)
File
Address
Parameter Name
Parameter
Number
Type Notes
N10:0 Control Source P.000 Configurable 0 = Front Panel (Local)
1 = Terminal strip
2 = Option Port (Network)
3 = Serial Port (PC-host)
N10:1 Accel Time 1 (RAMP 1) P.001 Tun a bl e 1 = 0.1 sec
N10:2 Decel Time 1 (RAMP 1) P.002 Tun a bl e 1 = 0.1 sec
N10:3 Minimum Speed P.003 Tun a bl e 50 = 5.0 Hz / 150 = 150 RPM
N10:4 Maximum Speed P.004 Tun able 50 = 5.0 Hz / 150 = 150 RPM
N10:5 Current Limit P.005 Tun a bl e 100 = 100%
N10:6 Second Menu Password P.006 Tun a bl e Note 1
N10:7 Term Strip Dig Inputs Config P.007 Configurable 0 through 12
N10:8 Term Strip Spd Ref Source P.008 Configurable 0 through 7
N10:9 Term Strip Anlg In Offset P.009 Tun a bl e 100 = 100
N10:10 Term Strip Anlg In Gain P.010 Tun a bl e 1000 = 1.000
N10:11 Term Strip Anlg In Configure P.011 Configurable 0 through 7
N10:12 Term Strip Anlg Out Source P.012 Tu na b le 0 through 3
N10:13 Output Relay Configuration P.013 Configurable 0 through 3
N10:14 Trim Reference Source P.014 Configurable 0 through 3
N10:15 Trim Gain Percentage P.015 Tun a bl e 999 = 99.9%
N10:16 Draw Gain Percentage P.016 Tun ab le 999 = 99.9%
N10:17 Accel Time 2 (RAMP 2) P.017 Tun a bl e 1 = 0.1 sec
N10:18 Decel Time 2 (RAMP 2) P.018 Tun a bl e 1 = 0.1 sec
N10:19 S-Curve Enable P.019 Configurable 0 = off; 1 = on
N10:20 Jog Speed Reference P.020 Tu n able 50 = 5.0 Hz / 150 = 150 RPM
N10:21 Jog Ramp Accel Time P.021 Tun a bl e 1 = 0.1 sec
N10:22 Jog Ramp Decel Time P.022 Tun a bl e 1 = 0.1 sec
N10:23 MOP Accel/Decel Time P.023 Tun ab le 1 = 0.1 sec
N10:24 MOP Reset Configuration P.024 Tun a bl e 0 to 2
N10:25 Stop Type P.025 Tun a bl e 0 = Coast; 1 = Ramp
Note 1: This parameter cannot be changed from the ControlNet network, or it is reserved. When writing to this parameter, use
a value of 0. When you read this parameter, you receive a value of 0.
