Owner's manual

4-6 GV3000/SE AC Drive ControlNet Network Communication Option Board
Table 4.5 explains the values that are available for words 2 - 5.
10
Digital In 3
(Reset)
This bit indicates the status of digital input 3.
11
Digital In 4
(Run/Jog)
This bit indicates the status of digital input 4.
12
Digital In 5 (FL)
This bit indicates the status of digital input 5.
13
Digital In 6
This bit indicates the status of digital input 6.
14
Digital In 7
This bit indicates the status of digital input 7.
15
Digital In 8
This bit indicates the status of digital input 8.
Word 1 –
Speed Reference
— This word indicates the speed reference being used by the drive.
Values range from ±4095.
Word 2 –
Selected Output 1
— This word indicates the value selected in parameter P.066. See table
4.5.
Word 3 –
Selected Output 2
— This word indicates the value selected in parameter P.067. See table
4.5.
Word 4 –
Selected Output 3
— This word indicates the value selected in parameter P.068. See table
4.5.
Word 5 –
Selected Output 4
— This word indicates the value selected in parameter P.069. See table
4.5.
Table 4.4 – Scheduled Drive Feedback Data (Continued)
Word: Bit: Description:
Table 4.5 – Signals That Can Be Displayed in Words 2 - 5
Value: Parameters
P.066 P. 0 6 7 P. 0 6 8 P. 0 6 9
0 Motor KW Motor Torque Power Factor Encoder Counts
1
Speed reference limited output
1
2
Speed reference plus OCL output
1
3
Speed feedback
1
4
Speed error
1
5
Speed PI output
1
6
OCL feedback
1
7
OCL error
1
