4-6
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
This parameter
selects the drive
control source.
The drive will
respond to the
reference, forward/
reverse, run/jog, and
start commands
(inputs) only from the
source selected in
this parameter.
Parameter Range: LOCL = Local keypad/display
rE = Terminal strip remote inputs
OP = Option port
SErL = Serial port (CS3000 or OIM)*
Default Setting: LOCL
Parameter Type: Configurable
Refer also to parameters: P.007 Terminal Strip Digital Inputs Configure
P.008 Terminal Strip Speed Reference Source
P.063 Option Port: Network Reference Source
*For more information about the Control and Configuration Software (CS3000), refer to instruction manual D2-3348.
For more information about the GV3000/SE OIM (Operator Interface Module, M/N 2RK3000), refer to instruction
manual D2-3342.
ATTENTION: In V/Hz regulation, if P.000 (Control Source) is set to
OP (Option Port), and P.062 is set to 1 (Hold Last Reference), and the
drive loses communication with the network, the drive will maintain the
last frequency command sent to it. Ensure that driven machinery, all
drive-train mechanisms, and application material are capable of safe
operation at the maximum operating speed of the drive. Failure to
observe this precaution could result in bodily injury.
The selected drive control source is determined primarily by the value in P.000.
However, if P.000 = rE, then the REM/LOC input may toggle the control source
between the local keypad and the terminal strip. See P.007 (Terminal Strip Digital
Inputs Configure).
Depending on the control source selected, the AUTO/MAN key can be used to
switch between speed reference sources as shown in table 4.1.
P.000 Control Source
!
To prevent unauthorized password use, a zero value (not the saved password
value) is displayed whenever this parameter is accessed.
Note that parameter values and the local keypad status are retained through a line
dip or power shutdown.
4.5 First Menu Parameters
The First Menu contains General parameters that are most commonly used for
simple applications. No password is required to access them. These parameters
apply to both vector and V/Hz programming and are described in detail in section
4.5.1.
4.5.1 First Menu General Parameter Descriptions (P.000 to P.006)
