3-6
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
3.5 The Keypad
The drive's keypad has nine membrane keys that are used to monitor, program, and
control the drive.
Use the AUTO/MAN key to switch between the auto speed
reference and the manual speed reference as shown below.
AUTO/MAN
Status
AUTO selected
MAN selected
Control Source (P.000)
Local keypad/display
(P.000=LOCL)
Terminal strip remote
inputs (P.000=rE)
Option port (P.000=OP)
Serial port (P.000=SErL)
Local keypad/display
(P.000=LOCL)
Terminal strip remote
inputs (P.000=rE)
Option port (P.000=OP)
Serial port (P.000=SErL)
Speed Reference
Source
Terminal strip
Terminal strip
Network
Terminal strip
Local keypad/display
or OIM/CS3000
Local keypad/display
or OIM/CS3000
Local keypad/display
or OIM/CS3000
Local keypad/display
or OIM/CS3000
ATTENTION: When switching from auto to manual,
or manual to auto, the drive will ramp to the reference
level provided by the new source at the rate specified
in P.001 (Accel Time 1), P.002 (Decel Time 1), P.017
(Accel Time 2), or P.018 (Decel Time 2). Be aware
that an abrupt speed change may occur depending
upon the new reference level and the rate specified in
these parameters. Failure to observe this precaution
could result in bodily injury.
If the control source is changed, the AUTO/MAN selection may be
changed as well. When the control source is changed to OP or rE,
the AUTO/MAN selection is forced to AUTO. If the control source
is changed to LOCL or SErL, the AUTO/MAN selection is forced to
MANUAL. However, if the control source is changed from LOCL to
SErL or vice versa, the AUTO/MAN selection is not changed.
Note that this key is not active if the control source is SErL. Refer
to the P.000 parameter description for more information on control
source selection.
Refer to the following parameters for more information on the
AUTO/MAN key:
• P.052 AUTO/MAN Key Disable
• P.053 Manual Reference Preset Enable
!
AUTO
MAN
