Software Start-Up and Ref. Owner manual

2-4
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
Step 2. Select Program Mode
In this step, you will select program mode, which gives you access to the First Menu
General (P) parameters.
Step 2.1 Press the PROGRAM key.
AUTO
MAN
Forward
Reverse
PROGRAM
RUN
JOG
STOP
RESET
START
ENTER
SPEED
VOLTS
AMPS
Hz
Kw
TORQUE
Password
RUNNING
REMOTE
JOG
AUTO
FORWARD
REVERSE
PROGRAM
The PROGRAM LED is on and the First
Menu General (P) parameters can be
accessed.
Step 2.2 Press the ENTER key.
The first General (P) parameter in the First
Menu, P.000, is displayed.
AUTO
MAN
Forward
Reverse
PROGRAM
RUN
JOG
STOP
RESET
START
ENTER
SPEED
VOLTS
AMPS
Hz
Kw
TORQUE
Password
RUNNING
REMOTE
JOG
AUTO
FORWARD
REVERSE
PROGRAM
Step 3. Enter the Second Menu Password
This step is required to access the Second Menu General (P) parameters and
Vector (U) parameters.
Step 3.1 Press the £ key until P.006, Second Menu Password, is displayed.
This parameter allows you to enter the
password that allows access to the Second
Menu.
The Second Menu provides access to all the
parameters and the error log.
AUTO
MAN
Forward
Reverse
PROGRAM
RUN
JOG
STOP
RESET
START
ENTER
SPEED
VOLTS
AMPS
Hz
Kw
TORQUE
Password
RUNNING
REMOTE
JOG
AUTO
FORWARD
REVERSE
PROGRAM
