Software Start-Up and Ref. Owner manual

D-1
Default Parameter Settings
EUROPE
(P.049 = EUr)
LOCL
20.0
20.0
5.0 Hz
150 RPM
50.0 Hz
1400 RPM
100
150
N/A
0
0
0
1.000
2
0
0
0
0.0
0.0
20.0
20.0
ON
ON
5.0 Hz
150 RPM
20.0
20.0
20.0
0
0
0
0
JAPAN
(P.049 = JPn)
LOCL
20.0
20.0
5.0 Hz
150 RPM
52.7 Hz
1500 RPM
100
150
N/A
0
0
0
1.000
2
0
0
0
0.0
0.0
20.0
20.0
ON
OFF
5.0 Hz
150 RPM
20.0
20.0
20.0
0
0
0
0
Parameter Name
Control Source
Accel Time 1
Decel Time 1
Minimum Speed P.048 = U-H
P.048 = UEC
Maximum Speed P.048 = U-H
P.048 = UEC
Current Limit P.048 = U-H
P.048 = UEC
Second Menu Password
Terminal Strip Digital Inputs Configure
Terminal Strip Speed Reference Source
Terminal Strip Analog Input Offset
Terminal Strip Analog Input Gain
Terminal Strip Analog Input Configure
Terminal Strip Analog Output Source
Output Relay Configuration
Trim Reference Source
Trim Gain Percentage
Draw Gain Percentage
Accel Time 2
Decel Time 2
S-Curve Enable P.048 = U-H
P.048 =UEC
Jog Speed Reference P.048 = U-H
P.048 =UEC
Jog Ramp Accel Time
Jog Ramp Decel Time
MOP Accel/Decel
MOP Reset Configuration
Stop Type
Function Loss Response
Forward/Reverse Configuration
APPENDIX D
Default Parameter Settings
First and Second Menu General Parameters
Parameter
No.
P.000
P.001
P.002
P.003
P.004
P.005
P.006
P.007
P.008
P.009
P.010
P.011
P.012
P.013
P.014
P.015
P.016
P.017
P.018
P.019
P.020
P.021
P.022
P.023
P.024
P.025
P.026
P.027
USA
(P.049 = USA)
LOCL
20.0
20.0
5.0 Hz
150 RPM
60.0 Hz
1722 RPM
100
150
N/A
0
0
0
1.000
2
0
0
0
0.0
0.0
20.0
20.0
ON
OFF
5.0 Hz
150 RPM
20.0
20.0
20.0
0
0
0
0
