Software Start-Up and Ref. Owner manual
Table Of Contents
- GV3000/SE AC General Purpose (V/Hz) and Vector Duty Drive, 1 - 20 HP, 230V AC Software Start-Up and Reference Manual D2-3387-5
- Important User Information
- Document Update
- Summary of Changes
- Table of Contents
- List of Figures
- List of Tables
- Preface
- Chapter 1 - Starting Up the Drive for Volts/Hertz Regulation
- Chapter 2 - Starting Up the Drive for Vector Regulation
- Chapter 3 - Using the Keypad/Display To Program, Monitor, and Control the Drive
- Chapter 4 - Programming Reference
- Chapter 5 - Troubleshooting the Drive Using Error Codes
- Appendix A - Alphabetical Listing of Parameters
- Appendix B - Record of User Parameter Settings
- Appendix C - Power Module-Dependent Parameter Default Values (230 V Series)
- Appendix D - Default Parameter Settings
- Appendix E - Configuring the Digital Inputs When the RMI Board Is Installed in the Drive
- Appendix F - Using the Terminal Strip Analog Input
- Appendix G - Drive Regulation Overview
- Back Cover / Publication D2-3387-5 July 2013
B-2
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
Parameter No. Setting Date
Second
Menu
General
(cont'd)
P.040
P.041
P.042
P.043
P.044
P.045
P.047
P.048
P.049
P.050
P.051
P.052
P.053
P.054
P.055
P.060
P.061
P.062
P.063
P.064
P.065
P.066
P.067
P.068
P.069
P.090
P.091
P.095
P.098
P.099
Parameter Name
Motor Overload Enable
Motor Overload Type
Line Dip Ride Through Time
Fault Auto Reset Attempts
Fault Auto Reset Time
Output Phase Loss Enable
Carrier Frequency (kHz)
Volts/Hertz or Vector Regulation
Country Defaults
Restore Defaults
Programming Disable
AUTO/MAN Key Disable
Manual Reference Preset Enable
Level Sense Start Enable
STOP/RESET Key Disable
Network Drop Number
Network Connection Type
Option Port: Communication Loss Response
Option Port: Network Reference Source
Option Port: Network Trim Reference Source
Option Port: Type and Version
Network Output Register 1 Source
Network Output Register 2 Source
Network Output Register 3 Source
Network Output Register 4 Source
Diagnostics Source
Diagnostics Display
Power Module Output Amps
Software Version Number
Power Module Type
