4-90
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
Parameter Range: 0.10 to 128.0
Default Setting: 2.00
Parameter Type: Tunable
Refer also to parameters: U.040 Outer Control Loop Feedback Source
U.041 Outer Control Loop Lead/Lag Select
U.042 Outer Control Loop Lead/Lag Low Frequency
U.043 Outer Control Loop Lead/Lag Ratio
U.044 Outer Control Loop Reference Gain
U.046 Outer Control Loop Integral Gain
U.047 Outer Control Loop Trim Range Percentage
U.048 Outer Control Loop Proportional Trim Enable
See Appendix G for the outer control loop block diagram.
This parameter
selects the
proportional gain of
the outer control loop
PI amplifier.
U.044 Outer Control Loop Reference Gain
This parameter
specifies the gain to
be applied to the
reference entering
the outer control
loop.
Parameter Range: -5.000 to +5.000
Default Setting: 1.000
Parameter Type: Tunable
Refer also to parameters: U.040 Outer Control Loop Feedback Source
U.041 Outer Control Loop Lead/Lag Select
U.042 Outer Control Loop Lead/Lag Low Frequency
U.043 Outer Control Loop Lead/Lag Ratio
U.045 Outer Control Loop Proportional Gain
U.046 Outer Control Loop Integral Gain
U.047 Outer Control Loop Trim Range Percentage
U.048 Outer Control Loop Proportional Trim Enable
See Appendix G for the outer control loop block diagram.
U.045 Outer Control Loop Proportional Gain
