4-81
Programming Reference
U.018 AC Line Volts
The phase-to-phase
line voltage provided
to the drive input
power terminals.
The value entered
should be within 10%
of actual line voltage.
Parameter Range: 180 to 300 VAC
Default Setting: 230
Parameter Type: Configurable
Refer also to parameters: N/A
U.019 Flux Current Regulator Proportional Gain
This parameter
determines the
performance of the
magnetizing current
regulator.
For most
applications, it is
recommended that
this parameter not be
changed.
Parameter Range: 0.10 to 31.99
Default Setting: Power Module-dependent, see Appendix C
Parameter Type: Tunable
Refer also to parameters: U.020 Flux Current Regulator Integral Gain
U.020 Flux Current Regulator Integral Gain
This parameter
determines the
performance of the
magnetizing current
regulator.
For most
applications, it is
recommended that
this parameter not be
changed.
Parameter Range: 10.0 to 628.0 radians/second
Default Setting: Power Module-dependent, see Appendix C
Parameter Type: Tunable
Refer also to parameters: U.019 Flux Current Regulator Proportional Gain
