GV3000/SE 230 VAC Drive, Software Reference Version 6.04
P.091 Diagnostics Display (continued)
P.095 Power Module Output Amps
This parameter
displays the
maximum output
current rating of the
drive. The maximum
value of Current Limit
(P.005) corresponds
to P.095.
Parameter Range: N/A
Default Setting: N/A
Parameter Type: Read only
Refer also to parameters: P.005 Current Limit
For example, if P.095 = 11.0 and P.005 = 110% of maximum, then the maximum
output current rating with no overload rating (100% rating) = 10.0 amps.
Four-Character Display
P.090 = 1, terminal strip digital inputs 4 3 2 1
P.090 = 2, terminal strip digital inputs 8 7 6 5
P.090 = 4, RMI digital inputs 4 3 2 1
P.098 Software Version Number
The parameter
displays the software
version number.
Parameter Range: N/A
Default Setting: N/A
Parameter Type: Read only
Refer also to parameters: N/A
P.099 Power Module Type
This parameter
displays the type of
Power Module the
drive is configured
for.
The Power Module type is displayed in the format V.nnn where V represents the
drive's voltage rating (2 = 230V, 4 = 460V, 5 = 575V), and nnn represents
horsepower. For example, the display 2.010 represents 230V, 10 HP.
Parameter Range: N/A
Default Setting: N/A
Parameter Type: Read only
Refer also to parameters: N/A
