4-18
GV3000/SE 230 VAC Drive, Software Reference Version 6.04
This parameter
allows for correcting
any offset in the
terminal strip analog
input prior to the
signal reaching the
drive.
This parameter is not
used if the terminal
strip analog input is
used as vector
torque reference
(U.000 = 1).
P.008 Terminal Strip Speed Reference Source (continued)
Table 4.3 – Acceptable P.007 and P.008 Selection Combinations
Parameter Range: -900 to +900*
Default Setting: 0
Parameter Type: Tunable
Refer also to parameters: P.000 Control Source
*For 0 to 10 V (or -10 V to +10 V input), a value of +1 equals an offset of approximately 10 mV.
For 0 to 20 mA input, a value of +1 equals an offset of approximately 20 µA.
For more information about the analog input, refer to Appendix F.
= Selection combination is acceptable.
P.007/P.008 Selection Example
If you want to select the MOP as the speed reference source, P.008 must be set to 1.
Next, select the value for P.007 using table 4.3. Following the 1 column down
under P.008 Selections, the acceptable selections for P.007 are 4, 5, 6, 7, or 12.
If an optional RMI board is installed in the drive, refer to Appendix E for more
information regarding digital input configuration.
P.009 Terminal Strip Analog Input Offset
0
1
2
3
4
5
6
7
8
9
10
11
12
01234567
P.008 Selections
P.007
Selections
