Programming Reference
This parameter
selects the source of
the terminal strip
speed reference.
The terminal strip
speed reference is
used when:
• the terminal strip
is the selected
control source
(P.000 = rE)
or
• the local keypad
or serial port is
the selected
control source
(P.000 = LOCL
or SErL) and
AUTO is
selected (AUTO
LED is on).
Parameter Range: 0 = Analog reference. (Digital inputs 6, 7, and 8 are
not used. See P.007.)
1 = MOP selection. (Uses terminal strip digital input
6 for the MOP increment and digital input 7 for
the MOP decrement function. Digital input 8 is
not used.)
2 = Two (2) preset speeds. (Uses terminal strip
digital input 6. Digital inputs 7 and 8 are not
used.)
3 = Four (4) preset speeds. (Uses terminal strip
digital inputs 6 and 7. Digital input 8 is not used.)
4 = Eight (8) preset speeds. (Uses all terminal strip
digital inputs.)
5 = Analog reference and one (1) preset speed.
(Uses terminal strip digital input 6. Digital inputs
7 and 8 are not used.)
6 = Analog reference and three (3) preset speeds.
(Uses terminal strip digital inputs 6 and 7. Digital
input 8 is not used.)
7 = Analog reference and seven (7) preset speeds.
(Uses terminal strip digital inputs 6, 7 and 8.)
Default Setting: 0
Parameter Type: Configurable
Refer also to parameters: P.007 Terminal Strip Digital Inputs Configure
P.031 Preset Speed 1
r.030 Digital Input Configuration
P.008 Terminal Strip Speed Reference Source
In selections 5, 6, and 7, a digital input will initiate the selected preset speed which
will override the analog speed reference. Refer to table 4.4 in the P.031 parameter
description.
The selection is dependent upon what is selected for parameter P.007 (Terminal
Strip Digital Inputs Configure). The selection made in P.007 determines what the
remaining free digital inputs are used for. See table 4.3 for acceptable
combinations.
