Instruction Manual

1 Publication 700-UM002B-EN-D - June 2010
Chapter 1
Product Overview
Bill of Material
Your 700-HX Multifunction Digital Timer product package includes the
following items:
Basic Product Information
Item No. Description Quantity
700-HX Digital Timing Relay 1
— 6-Language Instruction Sheet 1
— Rubber Gasket 1
Cat. No. Input
Voltage
Output Modes Timing Ranges Sockets Output Pins
700-HX86SA17 100…240
V AC
A mode: Signal ON-Delay 1
A-1 mode: Signal ON-Delay 2
A-2 mode: Power ON-Delay 1
A-3 mode: Power On-Delay 2
B mode: Repeat Cycle 1
B-1 mode: Repeat Cycle 2
D mode: Signal OFF-delay
E mode: One Shot
F mode: Cumulative
Z mode: On/Off duty adjustable repeat cycle
S mode:stop watch
toff: Flicker OFF start 1
ton: Flicker ON start 1
toff-1: Flicker OFF start 2
ton-1: Flicker ON start 2
0.000…9.999 s
0.000…99.99 s
0.000…999.9 s
0.000…9999 s
0.000…99 min. 59 s
0.000…999.9 min.
0.000…9999 min.
0.000…99 h 59 min.
0.000…999.9 h
0.000…9999 h
700-HN100
700-HN125
SPDT 8
700-HX86SU24
12…24V
DC
24V AC
