Instruction Manual

Publication 700-UM002B-EN-D - June 2010
Appendix-3
Run Mode when Output Mode = Z
Function Setting Mode
Parameter
name
Parameter Setting range Dafault
value
Unit Set
value
Present
value,
cycle
time
Cycle
time
0.00 …99.99
(Time range: --,--s)
0.00
s
0.0 … 999.9
(Time range: ---,-s)
0.0
s
0 … 9999 (Time range: ----s) 0
s
0:00 … 99:59
(Time range: --min--s)
0:00
min; s
0.0 … 999.9
(Time range: ---,-min)
0.0
min
0 … 9999
(Time range: ----min)
0
min
0:00 … 99:59
(Time range: --h--min)
0:00
h; min
0.0 … 999.9
(Time range: ---,-h)
0.0
h
0 … 9999 (Time range:
----h)
0
h
0.000 … 9.999
(Time range: -,---s)
0.000
s
Present
value
Same as cycle time above Same
as left
Same
as left
Present
value,
ON
duty
ratio
ON
duty
ratio
0…100 0
%
Present
value
Same as cycle time above Same
as left
Same
as left
Parameter name Parameter Setting range Dafault
value
Unit Set
value
Time range
timr --,--s/---,-s/----s/--min--s/
---,-min/----min/--h--min/
---,-h/----h/-,---s
---
Timer mode
timm up down up ---
Output mode
outm a a-1 a-2 a-3 b b-1
d e f s
a ---
Output time
otim hold 0.01 to 99.99 hold s
Input signal width
iflt 20ms 1ms 20ms ---
Key protect level
kypt kp-1 kp-2 kp-3
kp-4 kp-5 kp-6
kp-7
kp-1 ---
