Instruction Manual

Publication 700-UM002B-EN-D - June 2010
Product Features 2-3
➊ The values are based on the set value.
❷ The value is applied for a minimum pulse width of 1 ms.
Characteristics
Inputs Input signals Start, reset
Input method No-voltage input via:NPN transistor or switching of contact
Start, reset Minimum input signal width: 1 or 20 ms (selectable)
Power reset Minimum power-opening time: 0.5 s (Except for A-3, B-1, and
F mode)
Control output SPDT contact output: 5 A at 250V AC, resistive load
(cosine=1)
Minimum applied load: 10 mA at 5V DC (failure level: P,
reference value)
External Power Supply No
Key Protect Yes
Memory backup EEP-ROM (overwritten 100,000 times min.), which can store
data for 10 years min.
Accuracy of Operating Time and Setting Error ➊ Power-ON start: +-0.01% +-50 ms max.*
* to be rated against set value
Signal start: +- 0.005 +-30 ms max. *
* to be rated against set value
Signal start at transistor output model: +- 0.005% +-3 ms
max. ➋
If the set value is within the sensor waiting time
(250 ms max.)
Electrical Ratings
Insulation resistance 100 MΩ min. (at 500V DC)
Dielectric strength 2000V AC, 50/60Hz for 1 min. between current-carrying terminals and
non-current-carrying metal parts
(1000V AC for 24V AC/12 to 24V DC type),
1000V AC, 50/60 Hz for 1 min. between non-continuous contacts
Noise immunity '+-1.5 kV (between power terminals) for 100 to 240V AC, +-480V for 24V AC/12
to 24VDC, and +-600V (between input terminals), square-wave noise by noise
simulator (pulse width: 100 ns/1 μs, 1-ns rise)
Static immunity ±8 kV (malfunction), ±15 kV (destruction)
Vibration resistance Malfunction 10…55 Hz with 0.35 mm single amplitude each in three directions for 10 min.
Shock resistance Malfunction
98 m/s
2
(approx. 10 G) each in three directions
Life expectancy Mechanical 10 million operations min.
Electrical 100,000 operations min. (5 A at 250V AC, resistive load)
EMC (EMI) EN61812-1
Emission Enclosure: EN55011 Group1 class A
Emission AC mains: EN55011 Group1 class A
(EMS) EN61812-1
Immunity ESD: EN61000-4-2: 4 kV contact discharge (level2)
8 kV air discharge (level3)
Immunity RF-interference: EN61000-4-3: 10 V/m
