Installation Instructions
PHOTOSWITCHr Bulletin 44N Zone Control Photoelectric Sensors
IMPORTANT: SAVE THESE INSTRUCTIONS FOR FUTURE USE.
Refer to the product catalog pages for additional information.
Description
The 44N provides an economical, noncontact, solution to zero
pressure accumulation conveyor systems by combining
built-in zone control with a photoelectric sensor. This simple
approach replaces the conventional mechanical switch
sensing device, central PLC, and large quantities of
interconnecting wiring.
The use of a photoelectric sensor eliminates the need for
minimum weight restrictions required by mechanically
actuated switches. The polarized retroreflective sensing mode
ensures reliable detection of even shiny packages over a
4.8 m (16 ft) range.
The 44N comes complete with micro QD connections to both
an upstream and downstream 44N along with a variety of
connection options for common pneumatic valves. Power for
the 44N and the valve is distributed through these
connections.
The zone logic of the 44N ensures that product being loaded
on the conveyor will be separated into zone length gaps thus
providing zero pressure accumulation throughout the
conveyor system. Once product has accumulated, it may be
released individually (singulate) or simultaneously as a train
(slug). This release is activated through an external contact
closure.
Features
S Singulation release
S Slug release
S Adjustable 200 ms…10 secs ON (run) delay
S NEMA 4X rated
Connection Types [mm (in.)]
44NSP--2JPBD5--Z01
S 838 (33) pigtail with 4-pin DC male micro QD
(downstream)
S 838 (33) pigtail with 4-pin DC female micro QD
(upstream)
S 304.88 (12 in.) cable for load
44NSP--2JPBD5--Z02
S 838 (33) pigtail with 4-pin DC male micro QD
(downstream)
S 838 (33) pigtail with 4-pin DC female micro QD
(upstream)
S Female right angle pico (M8) QD connector on a
533.4 (21 in.) cable for load
44NSP--2JPBD5--Z03
S 351 (15) pigtail with 4-pin DC male micro QD
(downstream)
S 351 (15) pigtail with 4-pin DC female micro QD
(upstream)
S Female right angle pico (M8) QD connector on a
533.4 (21 in.) cable for load
Specifications
Environmental
Certifications cULus Listed and CE Marked for all applicable
directives
Operating Environment NEMA 4, 4X, 6, 12, IP67
Operating Temperature
[C(F)]
-- 2 0 …+70° (--4…+158°)
Vibration 10…55 Hz, 1 mm amplitude, meets or exceeds IEC
60947--5--2
Shock 30 g with 1 ms pulse duration, meets or exceeds IEC
60947--5--2
Relative Humidity 5…95% (noncondensing)
Optical
Sensing Modes Polarized retroreflective
Sensing Range 50.8 mm…4.8 m (50.8 in…16 ft) with 92--39 reflector
Field of View 1.5°
Light Source Visible red (660 nm)
Adjustments On delay (200 ms…10 s), DIP switch
LED Indicators Green output LED indicator
Electrical
V oltage 10…30V DC
Current Consumption 20 mA max
Sensor Protection Overload, short circuit, reverse polarity, false pulse
Outputs
Response Time 2ms
Output Type PNP
Output Mode Light or dark operate selectable by dip switch (1 L.O.,
0 D.O.)
Output Current 100 mA @ 30V DC max
Mechanical
Housing Material Valoxr
Lens Material Acrylic
Supplied Accessories 129--130 mounting nut
Optional Accessories Mounting brackets, reflectors, cordsets
