MSR45E Safety Relay Expansion Module User Manual
Important User Information Because of the variety of uses for the products described in this publication, those responsible for the application and use of this control equipment must satisfy themselves that all necessary steps have been taken to assure that each application and use meets all performance and safety requirements, including any applicable laws, regulations, codes and standards.
MSR45E Safety Relay Expansion Module User Manual Content Approvals and Conformity Approvals and Conformity . . . . . . . . . . . . . . . . . . . . . . . . 1 The safety approval, performed by TÜV Rheinland is available on www.ab.com. The actual list of relevant safety data and applied standards is given in these documents. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MSR45E Safety Relay Expansion Module User Manual Note: The MSR45E safety relay expansion module is not a standalone safety relay module. It can only be used in conjunction with either an MSR41 or MSR42 control module. Terminal Configurations The safety output contact configuration of the MSR45E. Snap control & expansion housing module together. Use ribbon cable to electronically link devices.
MSR45E Safety Relay Expansion Module User Manual Color LED "FSD" Status Off No power at main module or no internal bus (e.g. no ribbon cable connection) Inspections The MSR45E modules have to be tested periodically – in accordance with valid regulations - by qualified and trained personnel to discover prohibited manipulations or unauthorized modifications. Table 1 Decommissioning Selection tables Cat. No.
MSR45E Safety Relay Expansion Module User Manual Technical Data Relay Outputs of Expansion Modules General data Nominal working mode Continuous process Temperature range Environment temp.: 0 ... +55°C Stock temp.: -25 ...
MSR45E Safety Relay Expansion Module User Manual Arc-limiting graph Characteristic curves for DC and AC applications (2C relay expansion module): Figure 6: Arc-limiting graph and lifespan curve for MSR45E expansion modules (secure off switching, no standing arc, max. 1 operating cycle / s) Characteristic curves for DC and AC applications (3C relay expansion module): Figure 7: Arc-limiting graph and lifespan curve for MSR45E expansion modules (secure off switching, no standing arc, max.
MSR45E Safety Relay Expansion Module User Manual Appendix Special MSR45E modules for existing customers. Selection Table Cat. No. Controller / Expansion modules 445L-105938 MSR45E-3C 2NO1NC, special safety relay Expansion Module 445L-104860 MSR45E-3C 3NO, special safety relay Expansion Module Terminal Configurations Type of Expansion module Schematic MSR45E 3C 3NO Safety Relay Expansion Cat.-No. 445L-104860 MSR45E 2NO1NC Safety Relay Expansion Cat.-No.
MSR45E Safety Relay Expansion Module User Manual EC Declaration of Conformity The undersigned, representing the manufacturer Rockwell Automation, Inc. 2 Executive Dr.
MSR45E Safety Relay Expansion Module User Manual Catalogue number 1 440R-P221AGS 440R-P226AGS-NNR 445L-104794-B*** 440R-P4NANS 445L-1**** Series 2 Description MSR41 base module MSR42 base module MSR42 base module customer configuration MSR45E expander module MSR45E expander module customer configuration 1) *Denotes characters representing options that do not impact the standards or directives cited on this DoC 2) If no series number is given, then all series are covered Document Control Number: SEN-039
