Tag Definitions Appendix D
06H Safety mat wiring detected on one of
the input pairs while the safety relay is
configured for ‘OR’ logic
Do one of the following:
• If there are no safety mats, check the input wiring (safety
mat wiring is crossed from normal dual-channel device
wiring)
• Change the safety relay to ‘AND’ logic.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
07H Mismatch between current switch
settings and setting stored during
power-up
Do one of the following:
• Change the switch settings to the correct values.
• Power cycle the safety relay.
• Reconfigure the safety relay.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
09H SPI compare fault
Do one of the following:
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
0BH ROM test failure
0CH Terminal S12 hardware input fault
0DH Terminal S22 hardware input fault
0EH Terminal S32 hardware input fault
0FH Terminal S42 hardware input fault
10H Terminal S34 hardware input fault
11H Pulse test fault on main transistor Do one of the following:
• Check wiring for shorts to 24V or other channels.
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
12H Pulse test fault of transistor for safety
output channel 1
13H Pulse test fault of transistor for safety
output channel 2
14H-1EH Internal plausibility test fault
Do one of the following:
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
1FH Different Single Wire Safety input signal
detected at Processor A than Processor B
20H, 21H Internal program fault
22H, 23H Rotary switch read error
24H Cross fault at processor pins for safety
outputs
25H Under voltage detected Do one of the following:
• Validate the electrical installation and appropriate supply
voltage is provided.
• Power cycle the safety relay.
• Reconfigure the safety relay.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
26H Fault detected in the other Processor If viewing the NonrecoverableFault_A tag, refer to
NonrecoverableFault_B tag.
If viewing NonrecoverableFault_B tag refer to
NonrecoverableFault_A tag.
Table 7 - GSR DI(S) NonRecoverableFault_A and NonRecoverableFault_B Fault Codes
Fault
Code
Description Corrective Action
