Slotx_GSR_DIS_S42 BOOL S42 Status – Indicates whether terminal S42 of circuit IN02
is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
Slotx_GSR_DIS_L12 BOOL L12 Status – Indicates whether terminal L12 is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
Slotx_GSR_DIS_S34 BOOL S34 Status – Indicates whether terminal S34 is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
Slotx_GSR_DIS_NonRecoverableFault_A SINT Non-Recoverable Fault Processor A – Indicates a
nonrecoverable fault has been recorded by Safety Processor
A. See Table 7 on page 52 for a list of non-recoverable fault
codes.
Slotx_GSR_DIS_NonRecoverableFault_B SINT Non-Recoverable Fault Processor B – Indicates a
nonrecoverable fault has been recorded by Safety Processor
B. See Table 7 on page 52
for a list of non-recoverable fault
codes.
Slotx_GSR_DIS_S12OpenWire BOOL S12 Open Wire - Indicates S12 open (0) and closed (1)
while S22 remained closed (1).
Slotx_GSR_DIS_S22OpenWire BOOL S22 Open Wire - Indicates S22 open (0) and closed (1)
while S12 remained closed (1).
Slotx_GSR_DIS_S32OpenWire BOOL S32 Open Wire - Indicates S32 open (0) and closed (1)
while S42 remained closed (1).
Slotx_GSR_DIS_S42OpenWire BOOL S42 Open Wire - Indicates S42 open (0) and closed (1)
while S32 remained closed (1).
Slotx_GSR_DIS_CrossLoopFault BOOL Cross Loop Fault – Indicates whether the safety relay has
detected a cross loop fault on one of the input circuits.
0 = No fault
1 = Cross loop fault
Slotx_GSR_DIS_InvalidSwitchSetting BOOL Invalid Switch Settings – Indicates the switch settings
changed after power-up of the safety relay.
0 = No fault
1 = Fault
Slotx_GSR_DIS_ResetHeldOn BOOL Reset Held On Fault – Indicates the reset signal On (1) for
longer than the maximum time of 3000 ms.
0 = No fault
1 = Fault
Table 7 - GSR DI(S) NonRecoverableFault_A and NonRecoverableFault_B Fault Codes
Fault
Code
Description Corrective Action
00H No fault None
01H RAM test fault
Do one of the following:
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
http://rockwellautomation.com/support
02H Stack over-/under-flow
03H Configuration mismatch between
Processors A and B
04H Internal timing fault
05H EEPROM read/write failure
Table 6 - GSR DI(S) Module Input Tags
Name Data Type Definition
