Appendix A
EtherNet/IP Network Interface Specifications
Specifications
Following are specifications for the Guardmaster EtherNet/IP Network Interface
Table 3 - General Specifications – Guardmaster EtherNet/IP Network Interface
Specification Description
Indicators 2 red/green status indicators:
– Module status
– Network status (Ports 1 and 2 combined)
2 green/yellow status indicators:
– Link 1 status
– Link 2 status
Power consumption, max 2.2 W @ 26.4V DC
Power dissipation, max 0.8 W @ 26.4V DC
Thermal dissipation, max 2.7 BTU/hr @ 26.4V DC
Dimensions (HxWxD), approx. 111.4 x 22.5 x 113.6 mm
(4.39 x 0.89 x 4.47 in.)
Enclosure type rating None (open-style)
Terminal base screw torque 0.8 N•m (7 lb•in)
Weight, approx. 180 g (0.4 lb)
Wiring category
(1)
(1) Use this conductor category information for planning conductor routing. Refer to publication 1770-IN041, Industrial Automation
Wiring and Grounding Guidelines.
1 – on power ports
2 – on communications ports
Wire size Power connections:
0.34... 2.1 mm
2
(22...14 AWG) solid or stranded copper wire
rated @ 75 °C (167 °F) or greater, 1.2 mm (3/64 in.) insulation max.
Ethernet wiring:
RJ45 connector according to IEC 60603-7, 2 or 4 pair
Category 5e min cable according to TIA 568-B.1 or
Category 5 cable according to ISO/IEC 24702.
North American temp code T6
IEC temp code T6
