34 Publication IASIMP-QS015C-EN-P - August 2011
Chapter 1 Hardware Selection
Export the IAB Configuration to ProposalWorks
Follow these steps to export the IAB configuration to ProposalWorks.
1. From the File menu, choose Export to
ProposalWorks File.
2. Enter a file name for the exports.
3. From the Files of Type pull-down menu,
choose ProposalWorks Files (*prp).
4. Click Open.
5. Click Yes or No to export the IAB
project to ProposalWorks and add
components to the BOM.
Refer to the table for details on how your selection affects the configuration files.
The IAB exports the projects into a
ProposalWorks file in the format you
selected. You can monitor progress at
the bottom left corner of the IAB
dialog box.
If You Select Then
Yes
The IAB configuration is exported to ProposalWorks. This option maintains a link between the IAB and
ProposalWorks files so that they always represent the same configuration.
No
The IAB configuration is exported to ProposalWorks. In this case, you can modify the configuration in
ProposalWorks or IAB. This option breaks the link between the IAB and ProposalWorks files so that
either can change without affecting the other.
