104 Publication IASIMP-QS015C-EN-P
Chapter 5 Faceplate Logix Integration
Add-On Instruction Program Tag Listing and Function
This table provides the interface tag names and functions that are within the Add-On Instructions. You can
read from and write to these tags from your specific application logic. This provides control and monitoring
of your configured devices.
ArmorStart Command Tags
ArmorStart Set Value Tag
Tag Names Function Corresponding ArmorStart Device Tag
Cmd_JogFwdProg Commands to Jog Forward Out_ArmorStart_xxxJogFwd
Cmd_JogRevProg Commands to Jog Reverse Out_ArmorStart_xxxJogRev
Cmd_RunFwdProg Commands to Run Forward Out_ArmorStart_xxxRunFwd
Cmd_RunRevProg Commands to Run Reverse Out_ArmorStart_xxxRunRev
Cmd_ResetProg Initiates device Clear Fault Out_ArmorStart_xxxFaultReset
Cmd_OperProgReq Initiates Operator Control
N/A
Cmd_ProgOperReq Initiates Program Control
Cmd_ProgProgReq Initiates Program Control
Cmd_ProgToOperPermissive Allows Program to Operator Control Transfer
Cmd_OperToProgPermissive Allows Operator to Program Control Transfer
Tag Names Function Corresponding ArmorStart DeviceTag
Set_SpeedProg Sets Commanded Frequency Out_ArmorStart_xxx.CommandedFreq
