A–4 Specifications
Publication 2755-6.3
Base/Charger Unit Specifications
Description Specification
Catalog Number 2755-HCG-B
5V dc ± 10% @ 190 mA typical
Power Requirements
5V dc
±
10% @ 190 mA typical
12V dc ± 10% 400 mA typical
Sensitivity –94 dBm 10E–4 BER
Selectivity
250K Hz @3 dB points
1 MHz @ 50 dB points
Frequency Control Programmable Synthesizer
Frequency Range 2.4 to 2.5G Hz
Frequency Resolution 250K Hz steps
Frequency Stability
± 20 ppm
Durability 6 ft (8 m) drop to concrete
Operating Temperature
32_ F to 104_ F (0_ C to 40_ C)
Storage Temperature
-40_ F to 140_ F (-40_ C to 60_ C)
Humidity 5 to 95% noncondensing
Agency Certification
•CSA certified
•UL listed
