Maintenance and Troubleshooting 5–17
Publication 2755-6.3
Problem Probable Cause(s) Corrective Action
1. Battery charger is not
seated properly on the
battery charger.
1. Reseat the battery
adapter.
2. Defective battery adapter.
2. Replace the battery
adapter.
Station will not go into Charge
Mode (yellow solid indicator)
3. Defective battery.
3. Replace the battery.
Mode (yellow solid indicator)
4. Battery is not the proper
temperature.
4. Allow the battery adjust to
room temperature.
5. Faulty LED on battery
charger.
5. Contact Allen-Bradley
Global Technical Services
(GTS).
1. Battery is too hot. 1. Allow battery to cool down.
Station will not go into
Condition Mode (yellow
2. Battery is already
discharged.
2. Charge battery.
Condition Mode (yellow
flashing indicator)
3. Faulty LED.
3. Contact Allen-Bradley
Global Technical Services
(GTS).
Battery Becomes Hot
1. Battery is defective. 1. Replace battery
immediately.
Power Supply Shuts Down
Temporarily
1. Power line surge. 1. Power is automatically
reset.
