5–6 Maintenance and Troubleshooting
Publication 2755-6.3
2. Connect the 4-slot battery charger power supply to the 4-slot
battery charger.
Battery Charger
Power Supply
4-Slot Battery Charger
To Battery Charger
3. Connect the power supply cable to the battery charger power
supply and to the outlet supplying AC power. Make sure the
outlet box is properly grounded. If you are not sure, have the
outlet checked by a qualified electrician.
To Power Receptacle
To Battery Charger
Power Supply
Grounding Pin
