Maintenance and Troubleshooting 5–5
Publication 2755-6.3
In the 4-Slot Battery Charger
Before using the 4-slot battery charger (Catalog No. 2755-HCP-B2),
read all the instructions and cautionary markings on the 4-slot battery
charger, battery, and on any products that use the battery.
!
ATTENTION: To reduce the risk of injury, use the
4-slot battery charger only in the way it is intended to
be used. Other batteries or adapters may explode
causing personal injury and damage.
To help insure proper operation of the 4-slot battery charger and
batteries, refer to the following.
• Do not expose the battery charger to rain, snow, or direct sunlight.
• The battery charger can be used at 32_ F to 104_ F
(0_ C to 40_ C).
• The battery charger should be placed in a well ventilated area free
of airborne contaminants.
• Unplug the battery charger from the receptacle supplying AC
power before attempting to clean or change adapters in order to
reduce the risk of electrical shock.
• Dispose of dead batteries in accordance with all applicable codes.
• Do not disassemble, incinerate, modify, or short circuit batteries,
charger, or related components.
• Perform a battery conditioning cycle on all new NiCd batteries
before using to ensure that the battery is fully charged. Refer to
page 5–9 to condition a battery.
To charge the battery in the 4-slot battery charger:
1. Mount the 4-slot battery charger horizontally as shown below.
