3–4 Configuring Your Scanner
Publication 2755-6.3
Description Default Setting
Beep After Good Decode Enabled
UPC/EAN Security Level 0
Decode Redundancy 0
UPC-A Preamble System Character
UPC-E Preamble System Character
Pause Duration 0
Prefix Value None
Suffix Value
7013 ( <Enter> for wedges,
<CR/LF> for serial devices)
Scan Data Transmission Format Data As Is
Laser Control
Laser On Time-Out 3 Seconds
RS-232C Options
Baud Rate 9600
Parity Odd
Check Parity Enabled
Hardware Handshaking None
Software Handshaking None
Serial Response Time-out 2 Seconds
Stop Bit Select 2
ASCII Data Format 7-bit
RTS Line State Low
Intercharacter Delay 0
Transmit Code ID Character Disabled
Transmit AIM Code ID Disabled
Ignore Unknown Characters Enabled
International Keypad Emulation Disabled
Table continued on the next page.
