Configuring Your Scanner 3–3
Publication 2755-6.3
Scanner Default Settings
The following table lists the default settings for the standard and
extended range scanners.
Description Default Setting
Host Interface None
Code Types All Enabled
Code Lengths
Code 39 1 to 55
Code 128 3 to 55
Codabar 2 to 55
I 2 of 5 14
D 2 of 5 14
MSI Plessey 1 to 55
Decode Options
Transmit UPC-A Check Digit Enabled
Transmit UPC-E Check Digit Enabled
Convert UPC-E to UPC-A Disabled
EAN Zero Extend Disabled
Transmit No Decode Message Disabled
Decode UPC/EAN Supplemental Disabled
ITF-14/EAN-13 Conversion Enabled
Transmit Code 39 Check Digit Disabled
MSI Plessey Check Digit 1
Buffer Code 39 Disabled
Beeper Volume High
Table continued on the next page.
