5–2 Communication Setup (Synapse Cable)
Publication 2755-6.4
Setting RS-232 Synapse Cable Options
This section defines the communication options available when the
scanner is connected to one of these RS-232 Synapse cables:
• Catalog No. 2755-HFC-SR2-01
• Catalog No. 2755-HFC-SR3-01
Default Settings
Scanning the Set RS-232 Synapse Cable Defaults bar code sets the
following parameters:
Parameter Default Setting
Refer to
Description
on Page:
Programming
Guide ➀
Page Reference
Host Standard RS-232 5–3 2-3
Baud Rate 9600 5–3 2-4
Parity None 5–4 2-5
Check Parity Enabled 5–4 2-6
Stop Bits 1 5–4 2-6
Data Bits 8 5–4 2-6
Hardware
Handshaking
None 5–5 2-7
RTS State Low 5–5 2-7
Software
Handshaking
None 5–6 2-8
Beep on BEL Enabled 5–7 2-9
Unknown Characters
Send Bar Codes With
Unknown Characters
5–7 2-9
Response Timeout 2 seconds 5–7 2-10
Parameter Set Set #1 5–8 2-12
➀ Programming Guide for 2-D Bar Code Scanners (Publication 2755-6.7).
