Transferring Via the Data Highway Plus
Chapter 4
and Remote I/O
4-8
22559
++"*(-!" (.'%( ( '%#. ' &(,
%, ))%#,#(' #%
))%#,#(' #% (&&',
%, #*,(*/
(.'%( ))%#,#(' #%
'%#. (,#(' ,
$
*(-)
(-% #!"(. /,
/)
*++
(% *#! *++ (, +
&(, *#! *++ (, +
*(!*&&#'! *&#'% (' #!-*,#('
-#,
2
Choose Select Application File and select the application you want to
download. If there are no applications in the selected directory, choose
Select Directory to change to the directory for the application file you
want to download.
If the application has been configured for Pass-Through you’ll see the
location data (Rack, Group, Module and PLC Type). You can’t change
these. If no location data appears in these fields, you can’t download the
application. You must first define the data in PanelBuilder.
3
Choose the PLC DH+ Address, and enter a number (0–77 octal).
4
If you have two Data Highway Plus networks joined by a connecting
module or “bridge”, assign a number from 0–77 (octal) to the Local
Bridge Address, and a number from 0–376 (octal) to the Remote Bridge
Address.
Important
To download the application file, you must define both the
local and remote bridge addresses, or set them to “Not Used”.
Note
The changes you make here will apply only to this download
operation, and won’t be saved with the selected application, or replace the
parameters configured in the application.
