Transferring Via the Data Highway Plus
Chapter 4
and Remote I/O
4-2
PLC Controller Series/Revision Requirements
Verify that your PLC controller can perform Pass-Through file transfers.
The following table lists the PLC controller series and revisions that
support Pass-Through file transfers.
Processor Series Revision
PLC-5/11
All All
PLC-5/15 B N or later
PLC-5/20 All All
PLC-5/25 A J or later
PLC-5/30 A B or later
PLC-5/40 A
B
E or later
B or later
PLC-5/60 A
B
E or later
B or later
PLC-5/250 All All
This table lists the PanelView 1200 hardware and firmware revisions, and
PanelBuilder software revisions that are required for Pass-Through:
PanelView 1200 Hardware Series A, Rev B or later
PanelView 1200 Firmware Version 3.0 or later
PanelBuilder Software (for DOS) Version 3.0 or later
PanelBuilder 1200 Software (for Windows) Version 5.0 or later
PanelView 1200 Transfer Utility Software Version 5.01 or later
Pass-Through Utility Version 3.01 or later
To download an application file over the Data Highway Plus and Remote
I/O networks to the PanelView 1200 terminal you must follow these steps:
1 Configure the file’s Pass-Through parameters in PanelBuilder.
2 Configure the Pass-Through parameters in the PanelView 1200 terminal
if you’re using the manual configuration. If the existing application is
already set up in the terminal you don’t need to do this.
3 Prepare the PanelView 1200 Transfer Utility for downloading.
a Define the PanelView location data.
b Define the Programming Terminal Configuration.
c Download the application file.
This chapter offers detailed instructions on each of these steps.
Downloading Application Files
over Data Highway Plus
