Setting Up the PanelView 1200
Chapter 2
Transfer Utility
2-3
Communication Cable Required for Upload/Download
If you want to transfer applications serially, you need the following:
RS-232 Serial (Upload/Download) Cable (Catalog No. 2711-NC1) for
connecting the personal computer to the PanelView 1200 terminal
Equipment Required for Pass-Through
You need the following equipment if you want to transfer applications via
the Data Highway Plus:
PLC-5 processor (for PLC series/revision requirements, see Chapter 4,
Transferring Via the Data Highway Plus and Remote I/O).
One of the following Allen-Bradley Data Highway Plus Interface
modules:
1770-KF2/1785-KE
1784-KL
1784-KT
1784-KT2
1784-KTK1
1784-PCMK
Equipment Required for EPROMs and EEPROMs
You need the following equipment if you want to burn EPROMs:
EPROM burner—must be able to accept a simple dump of Intel Hex
format data and use 27C256 or 27C512 type EPROMs without special
commands or operations.
27C256 or 27C512 type EPROMs
EPROM chip sets (Catalog No. 2711-NM1) for Series A to C terminals are
available from Allen-Bradley.
