Publication 2706-UM017C-EN-P - March 2006
3-14 InView Communication Module Connections
The illustration below shows how to connect an InView DH-485
communication module to a MicroLogix or SLC controller using the
AIC+ link coupler (Catalog No. 1761-NET-AIC).
InView Display Connected to MicroLogix or SLC with an AIC+
Cable Cat. No.
1761-CBL-AS03 Cat. No.
1761-CBL-AS09
Cable
Cat. No. 1761-CBL-AS03
Cat. No. 1761-CBL-AS09
Cat. No.
1761-CBL-HM02
1761-CBL-AM00
Cat. No. 1747-CP3
To 24V dc Power
Cable Cat. No.
1747-C10 Cat. No.
1747-C11 Cat. No.
1747-C20
Cat. No.
1761-CBL-HM02
1761-CBL-AM00
AIC+
1761-NET-AIC
AIC+
1761-NET-AIC
AIC+
1761-NET-AIC
AIC
1747-AIC
Belden 9842
To InView Comm Module
Do not connect the InView
Communication Module to Port
3 of the AIC+ when Port 3 is
networked to other devices.
MicroLogix 1000, 1200, 1500LSP
SLC 5/03, 5/04, 5/05
MicroLogix 1000, 1200, 1500LSP
Channel 0 Port
InView display
RS-232 Port 77156-094
2706-P22R
2706-P4x
2706-P7x
2706-P9x
InView display
RS-232 Port 77156-094
DH-485 Comm
Module
RS-232 Port
77156-094
2706-P22R
2706-P4x
2706-P7x
2706-P9x
DH-485 Comm
Module
DH-485 Comm
Module
2706-P22R, 2706-P4x,
2706-P7x,2706-P9x
InView display
