Appendix B
Adapter Parameters
Appendix B provides information about the adapter parameters.
The parameters in the adapter are numbered consecutively. However,
depending on which configuration tool you use, they may have different
numbers.
Topic Page
About Parameter Numbers
B-1
Parameter List B-1
About Parameter Numbers
Configuration Tool Numbering Scheme
• HIM
• DriveExplorer
• DriveTools SP
The adapter parameters begin with parameter 1. For
example, Parameter 04 - [P-DP Addr Actual] is
parameter 04 as indicated by this manual.
Parameter List
Parameter
No. Name and Description Details
01 [Mode]
Displays the Single or Multi-Drive operating mode
selected with the jumper J2 on the adapter.
Default: N/A
Values: 0 = Single Drv
1 = Multiple Drv
Type: Read Only
02 Reserved —
03 Reserved —
04 [P-DP Addr Actual]
Profibus Node Address actually used by the
adapter.
Default: N/A
Minimum: 0
Maximum: 127
Type: Read Only
