Troubleshooting 8-5
In Multi-Drive mode, it is not possible to connect a peripheral device
such as a HIM or 22-SCM-232 (DriveExplorer). Therefore, the
following adapter diagnostic items can only be accessed via the Profibus
network.
Adapter Diagnostic Items in Multi-Drive Mode
No. Name Description
1 Field Flash Cnt The number of Firmware Updates.
2 Adapter Events The number of events in the event queue.
3 Drv 0 Reference Reference from Profibus returned to DSI Drive 0.
4 Drv 0 Logic Cmd Command from Profibus returned to DSI Drive 0.
5 Drv 0 Logic Sts Status of the Drive 0 returned to Profibus.
6 Drv 0 Feedback Feedback from Drive 0 returned to Profibus.
7 Drv 1 Reference Reference from Profibus returned to DSI Drive 0-1.
8 Drv 1 Logic Cmd Command from Profibus returned to DSI Drive 0-1.
9 Drv 1 Logic Sts Status of the Drive 0-1 returned to Profibus.
10 Drv 1 Feedback Feedback from Drive 0-1 returned to Profibus.
11 Drv 2 Reference Reference from Profibus returned to DSI Drive 0-2.
12 Drv 2 Logic Cmd Command from Profibus returned to DSI Drive 0-2.
13 Drv 2 Logic Sts Status of the Drive 0-2 returned to Profibus.
14 Drv 2 Feedback Feedback from Drive 0-2 returned to Profibus.
15 Drv 3 Reference Reference from Profibus returned to DSI Drive 0-3.
16 Drv 3 Logic Cmd Command from Profibus returned to DSI Drive 0-3.
17 Drv 3 Logic Sts Status of the Drive 0-3 returned to Profibus.
18 Drv 3 Feedback Feedback from Drive 0-3 returned to Profibus.
19 Drv 4 Reference Reference from Profibus returned to DSI Drive 0-4.
20 Drv 4 Logic Cmd Command from Profibus returned to DSI Drive 0-4.
21 Drv 4 Logic Sts Status of the Drive 0-4 returned to Profibus.
22 Drv 4 Feedback Feedback from Drive 0-4 returned to Profibus.
23 Profibus Rx Errors Present value of the Profibus Receive Error Counter register.
24 Profibus Tx Errors Present value of the Profibus Transmit Error Counter register.
25 Active drives number The number of active slave drives.
