Chapter 8
Troubleshooting
This chapter provides information for diagnosing and troubleshooting
potential problems with the adapter and network.
The adapter has three status indicators. They can be viewed on the
adapter or through the drive cover. See Figure 8.1.
Figure 8.1 Status Indicators (location on drive may vary)
Topic Page
Locating the Status Indicators
8-1
PORT Status Indicator 8-2
MOD Status Indicator 8-3
NET A Status Indicator 8-4
Adapter Diagnostic Items in Single Mode 8-4
Adapter Diagnostic Items in Multi-Drive Mode 8-5
Viewing and Clearing Events 8-6
Locating the Status Indicators
Number Status Indicator Description Page
➊ PORT DSI Connection Status 8-2
➋ MOD Adapter Status 8-3
➌ NET A Profibus Status 8-4
➍ NET B Not Used for Profibus —
➊
➋
➌
➍
➊
➋
➌
(Series A adapter shown)
