7-10 Using Multi-Drive Mode
The following table shows example settings for all five drives on the
node:
Important: Parameter A105 - [Comm Loss Action] in the drives that
are daisy chained is also used in Multi-Drive mode. If the
RS-485 daisy-chain cable is disconnected or broken, the
disconnected drives will immediately take the
corresponding Comm Loss Actions. Drive parameter A106
- [Comm Loss Time] is not used in Multi-Drive mode. For a
network disruption, adapter Parameters 09 - [Comm Flt
Action] and 10 - [Idle Flt Action] determine the action
taken for ALL of the drives on the Multi-Drive node.
Parameter addressing for Parameter Data in Multi-Drive mode is similar
to that in Single mode.
The parameter numbers (PNU) range from 1 to 2047. The parameter
numbers 1…1023 are used to access the drive or adapter parameters,
while parameter numbers 1024…2047 are used for accessing the adapter
fault codes, events and diagnostic items.
For details to access the drive parameters when the adapter is operated in
of Multi-Drive mode, see Parameter Message Request
on page 6-4.
PowerFlex 4-Class Drive Parameter Parameter Value
Number Name Drive
0
Drive
1
Drive
2
Drive
3
Drive
4
4/40/40P 4M 400
P36 P106P36[Start Source] 55555
P38 P108 P38 [Speed Reference] 5 5 5 5 5
A103 C302 C103 [Comm Data Rate]
(1)
(1)
The drive must be power cycled for a change to this parameter to take effect.
44444
A104 C303 C104 [Comm Node Addr]
(1)(2)
(2)
The settings for these parameters must match the respective parameter settings in the adapter
(Parameter 17 - [Drv 0 Addr through Parameter 21 - [Drv 4 Addr]).
12345
A105 C304 C105 [Comm Loss Action] 0 0 0 0 0
A106 C305 C106 [Comm Loss Time] 5 5 5 5 5
A107 C306 C102 [Comm Format]
(1)
00000
Multi-Drive Mode Parameter Data
