Configuring the Adapter 3-9
The following parameters provide information about how the adapter is
configured. You can view these parameters at any time.
Viewing the Adapter Configuration
Adapter Parameter Description
01 - [Mode] Displays the adapter operating mode selected with the Mode
Jumper J2.
Values
0 = Single Drv operation
1 = Multiple Drv operation
04 - [P-DP Addr Actual] Profibus Node Address actually used by the adapter.
05 - [P-DP Rate Actual] Profibus actual operating data rate.
12 - [DSI I/O Act] Indicates the Drives that are active.
Bit Definitions
Single Mode Multi-Drive Mode
Bit 0 = Drive
Bits 1…7 = Not Used
Bit 0 = Drive 0
Bit 1 = Drive 1
Bit 2 = Drive 2
Bit 3 = Drive 3
Bit 4 = Drive 4
Bits 5…7 = Not Used
