3-8 Configuring the Adapter
Changes to switch settings or some adapter parameters require that you
reset the adapter before the new settings take effect. You can reset the
adapter by cycling power to the drive or by using the following
parameter.
Set Parameter 08 - [Reset Module] to “1” (Reset Module).
Figure 3.5 Example Reset HIM Screen
When you enter “1” (Reset Module), the adapter will be immediately
reset. When you enter “2” (Set Defaults), the adapter will set all adapter
parameters to their factory-default settings. After performing a Set
Defaults, enter “1” (Reset Module) so that the new values take effect.
The value of this parameter will be restored to “0” (Ready) after the
adapter is reset.
Resetting the Adapter
!
ATTENTION: Risk of injury or equipment damage exists. If the
adapter is transmitting control I/O to the drive, the drive may fault when
you reset the adapter. Determine how your drive will respond before
resetting a connected adapter.
Value Description
0 Ready (Default)
1 Reset Module
2 Set Defaults
Reset Module
Parameter: #
008
Ready 0
VALUE LIMITS SEL 
