Getting Started 1-3
The adapter is compatible with Allen-Bradley PowerFlex 4-Class drives
and other products that support an internal DSI adapter. At the time of
publication, compatible products include:
• PowerFlex 4 drives (when used with DSI External Comms Kit)
• PowerFlex 4M drives (when used with DSI External Comms Kit)
• PowerFlex 40 drives
• PowerFlex 40P drives
• PowerFlex 400 drives
When operated in Multi-Drive mode (Chapter
7), the adapter provides
the means for up to five (5) PowerFlex 4-Class drives to operate on the
network and be represented as only one node.
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
Compatible Products
Required Equipment
❑ One adapter
❑ One 15.24 cm (6 in.) Internal Interface cable
❑ One floppy disc with GSD file
❑ One PowerFlex 4-Class DSI (Drive Serial Interface) Network
Communication Adapter Installation Instructions (publication
22COMM-IN002)
