Step 9: Replace the
Protective Covers and
Documenting the Change
1. Replace the protective covers in the reverse order of removal as
described in Step 2: Remove the Protective Covers
on page 4.
2. Install DPI cable (if present).
3. Record the installation of the new AC Line Snubber board and Resistors
and date of installation on the Field Installed Option label on the side of
the drive (as shown below).
Related Documentation
Allen-Bradley publications are available on the internet at
www.rockwellautomation.com/literature.
For . . . Read this document
Publication
Number
In depth information regarding the
operation of PowerFlex Digital DC drives
User Manual - PowerFlex Digital DC Drives 20P-UM001…
