Installation Instructions

PowerFlex

DC Drive - Frame A SCR Modules

for Drives with a Power Traces Circuit Board

What This Kit Includes

• SCR modules (3 for non-regenerative drives, 6 for regenerative drives)

• Mounting screws and washers (6 for non-regenerative drives, 12 for

regenerative drives)

• Gate leads (6 for non-regenerative drives, 12 for regenerative drives)

• Thermal Grease

• Static strap

Important:The SCR Modules supplied with this kit should only be used in

the following Frame A drives:

ATTENTION: Only qualified personnel familiar with DC

drives and associated machinery should plan or implement the

installation, start-up and subsequent maintenance of the system.

Failure to comply may result in personal injury and/or equipment

damage.

ATTENTION: To avoid an electric shock hazard, ensure that all

power to the drive has been removed before performing the

following.

ATTENTION: This drive contains ESD (Electrostatic

Discharge) sensitive parts and assemblies. Static control

precautions are required when installing, testing, servicing or

repairing this assembly. Component damage may result if ESD

control procedures are not followed. If you are not familiar with

static control procedures, reference A-B publication 8000-4.5.2,

“Guarding Against Electrostatic Damage” or any other

applicable ESD protection handbook.

230V AC Input 460V AC Input

Drive Current

Rating Code DC Amps

AC Line

Amps HP

Drive Current

Rating Code DC Amps

AC Line

Amps HP

7P0 7 5.7 1.5 4P1 4.1 3.3 2

9P0 9 7.4 2 6P0 6 4.9 3

012 12 9.8 3 010 10 8.2 5

020 20 16 5 014 14 11.4 7.5

029 29 24 7.5 019 19 15.5 10

038 38 31 10 027 27 22.1 15

055 55 45 15 035 35 28.6 20

045 45 36.8 25

052 52 42.5 30
