16 PowerFlex® DC Drive - Frame A Pulse Transformer Circuit Board
Total Resistance Values
Table C 230V AC Input Drives
Table D 460V AC Input Drives
3. Seal the TA potentiometer using RV (silicon).
Continue with Step 6: Install the New Pulse Transformer Board and
Existing Switching Power Supply Board on page 18.
Drive Current
Rating Code
DC
Amps
AC Line
Amps HP
Set RTA Value Using
TA Potentiometer
(Ohms)
7P0 7 5.7 1.5 34.971
9P0 9 7.4 2 45.333
012 12 9.8 3 34
020 20 16 5 61.2
029 29 24 7.5 42.207
038 38 31 10 32.211
055 55 45 15 22.255
073 73 60 20 16.767
093 93 76 25 13.161
110 110 90 30 11.127
Drive Current
Rating Code
DC
Amps
AC Line
Amps HP
Set RTA Value Using
TA Potentiometer
(Ohms)
4P1 4.1 3.3 2 59.707
6P0 6 4.9 3 40.8
010 10 8.2 5 40.8
014 14 11.4 7.5 29.143
019 19 15.5 10 64.421
027 27 22.1 15 45.333
035 35 28.6 20 34.971
045 45 36.8 25 27.2
052 52 42.5 30 23.538
073 73 59.6 40 16.767
086 86 70.3 50 14.233
100 100 81.7 60 12.24
129 129 105.4 75 9.488
