Instruction Manual

Rockwell Automation Publication 20D-PM001C-EN-P - July 2013 9
Preface
Purpose of This Manual
The purpose of this manual is to provide you with the information needed to
start-up, program and troubleshoot PowerFlex 700S Phase II Adjustable
Frequency AC drives.
Who Should Use This Manual
This manual is intended for qualified personnel. You must be able to program
and operate adjustable frequency AC drives. In addition, you must have an
understanding of the parameter settings and functions of this drive and
programmable controllers for PowerFlex 700S Phase II drives with DriveLogix.
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
Topic Page
Who Should Use This Manual 9
Additional Resources 9
General Precautions 11
Resource Description
PowerFlex 700S Phase II Drive, Frames 1…6 Installation
Instructions, publication 20D-IN024
Provides you with the information needed to install and
wire PowerFlex 700S Phase II frame 1…6 drives.
PowerFlex 700H and 700S Drives, Frames 9…14 Installation
Instructions, publication PFLEX-IN006
Provides you with the information needed to install and
wire PowerFlex 700S Phase II frame 9…14 drives.
PowerFlex 700S Phase II Reference Manual, publication
PFLEX-RM003
Provides detailed explanations and examples of
PowerFlex 700S Phase II drive control functions and
application programming.
Stegmann Feedback Option for PowerFlex 700S Drives
Installation Instructions, publication 20D-IN001
Provides instructions for installing the Stegmann
feedback option board for PowerFlex 700S drives.
Resolver Feedback Option for PowerFlex 700S Drives
Installation Instructions, publication 20D-IN002
Provides instructions for installing the resolver
feedback option board for PowerFlex 700S drives.
Multi-Device Interface for PowerFlex 700S Drives Installation
Instructions, publication 20D-IN004
Provides instructions for installing the multi-device
interface option board for PowerFlex 700S drives.
Second Encoder Option for PowerFlex 700S Drives with
Phase II Control Installation Instructions,
publication 20D-IN009
Provides instructions for installing the second encoder
option board for PowerFlex 700S drives.
SynchLink™ Board for PowerFlex 700S Drives with Phase II
Control Installation Instructions, publication 20D-IN010
Provides instructions for installing the SynchLink option
board for PowerFlex 700S drives.
DriveLogix5730 Controller User Manual, publication
20D-UM003
Provides information to help you develop projects for
DriveLogix controllers and establish communications
with PowerFlex 700S Phase II drives.
Logix5000 Controllers Common Procedures Programming
Manual, publication 1756-PM001
This publication links to a collection of programming
manuals that describe how you can use procedures that
are common to all Logix5000 controller projects.
Logix5000 Controllers General Instructions Reference
Manual, publication 1756-RM003
Provides a programmer with details about each
available instruction for a Logix-based controller.
Logix5000 Controllers Process Control and Drives
Instructions Reference Manual, publication 1756-RM006
Provides a programmer with details about each
available instruction for a Logix-based controller.
