- PowerFlex 700S High Performance AC Drive - Phase II Control, Programming Manual
- Summary of Changes
- Table of Contents
- Preface
- Chapter 1 - Drive Start-Up
- Chapter 2 - Programming and Parameters
- Chapter 3 - Troubleshooting
- Appendix A - Human Interface Module Overview
- Appendix B - Application Notes
- Appendix C - Control Block Diagrams
- Appendix D - PowerFlex 700S Permanent Magnet Motor Specifications
- Appendix E - ATEX Approved PowerFlex 700S, Phase II Drives in Group II Category (2) Applications with ATEX Approved Motors
- Appendix F - History of Changes
- Index
- Back Cover
Rockwell Automation Publication 20D-PM001C-EN-P - July 2013 3
Summary of Changes
This manual contains new and updated information.
New and Updated
Information
This table contains the changes made to this revision.
Changes to this manual for previous revisions are included in Chapter F History
of Changes on page 209
.
Topic Page
Updated the list of Additional Resources. 9
Updated the description of parameter 338 [Mtr I2T Spd Min] to include setting it to the
minimum value for the motor overload trip to vary in time at low speeds.
69
Updated the description of fault 15 “Inv OTemp Trip” to include a possible juntion temperature
fault condition.
146
Removed the “Input Voltage Range/Tolerance” topic from Chapter B Application Notes. 161
Added a note to the “Inverter Overload IT” block diagram for parameter 338 [Mtr I2T Spd Min]. 197
