Rockwell Automation Publication 20D-PM001C-EN-P - July 2013 161
Appendix B
Application Notes
For additional application notes, refer to the PowerFlex 700S Adjustable
Frequency AC Drive with Phase II Control Reference Manual, publication
PFLEX-RM003
.
Topic Page
DPI Communication Configurations 162
Motor Control Mode 164
Motor Overload 166
Motors with Compatible Thermistor Ratings 168
Setpt 1 Data 169
Setpt 2 Data 169
Stop Dwell Time 170
Sleep-Wake Mode 171
